Block Air Cylinders
‧Block Cylinders - CB Series


Block Air Cylinders

Product Specifications

Double acting block cylinders

CBQ  Side Mounting Type
CBQ...B  Side Mounting Type
  (piston with magnet)
CBB  Front Mounting Type
CBB...B  Front Mounting Type
  (piston with magnet)



  • All series of cylinder with magnet.
  • The choice of fixing is large and give more solution to integrate the cylinder in the mechanical part.
  • All with end cushions (φ16 ~ φ40) .

  • Product Character
    Bore size of cylinder (mm) φ16 φ20 φ25 φ32 φ40
    Port size M5 G 1/8 G 1/4
    Power fluid Filtered air with or without lubrication
    The range of pressure (kgf/cm²) 2 ~ 7
    Maximum pressure (kgf/cm²) 10.2
    The range of temperature (°C) 0 ~ 70
    The range of speed (mm/s) 50 ~ 500
