| Type |
PW2000 |
PW3000 |
PW4000 |
| Port size (G) |
1/8", 1/4" |
1/4", 3/8" |
1/2, 3/4" |
| Port size for pressure gauge (G)※ |
1/8" |
1/8" |
1/4 " |
| Fluid |
Air |
| Proof pressure (kgf/cm² ) |
15 |
| Max. operating pressure (kgf/cm² ) |
10.2 |
| Regulating range (kgf/cm² ) |
0.5 ~ 8.7 |
| Ambient and media temperature ( °C ) |
-5 ~ 60 With no freezing |
| Nominal filtration rating ( µm) |
PF:5 /PFM:1/ (95% filtered partide size) |
| Bowl capacity (cm³) |
15 |
20 |
45 |
| Bowl material |
Polycarbonate |
| Weight (kg) |
0.25 |
0.5 |
1.1 |
※ Only for round gauge
| Name / Type | Part No . |
Referance Page
|
| PW2000 | PW3000 | PW4000 |
| PR/PW (Blacket) |
W335 |
W423 |
W522 |
A-35 |
| Accessory (Optional) |
Pressure gauge
|
10 kgf/cm ²
| Round |
K40110 |
K40 110 |
K40210 |
A-36 |
| Square |
GK27510 |
GK27510 |
GK27510 |
A-36 |
|
4 kgf/cm²
| Round |
K40104 |
K40104 |
K40204 |
A-36 |
| Auto drain | N.C (Float type) ※ |
─ |
AD53 |
AD53 |
─ |
| (Dif ferential pressure type) |
AD62
|
─
|
─
|
─
|
※ Mini operating: N.C-1.5 kgf/cm² |
