G1/8 Pneumatically Actuated (PV-150)
Home > Products > Mechanical & Air Pilot Valve > Air Pilot Valve > G1/8 Pneumatically Actuated (PV-150)

G1/8 Pneumatically Actuated (PV-150)
‧G1/8 Pneumatically Actuated (PV-150)


G1/8 Pneumatically Actuated (PV-150)
G1/8 Pneumatically Actuated (PV-150)
G1/8 Pneumatically Actuated (PV-150)

Product Specifications
Model
PV-152-S
PV-152-D PV-153-D
Port thread size (Rc) 1/8"
Port amount 5/2 5/3
Used fluid Air
Pressure range (kgf/cm²) 1.5 ~ 8 2 ~ 7
Effective section area (mm²) 12 9
Ambient temperature (°C) 0 ~ 60
Weight (g) 60 80 100
